Draw Spike In Casting
In molding shop, it is used for driving the draw spike into the pattern and then rapping it for separation from the mould surfaces so that pattern can be easily withdrawn leaving the mold cavity without damaging the mold surfaces. Draw spike Draw spike is a tapered steel rod having a loop or ring at its one end and a sharp point at the other. The draw spike is a pointed steel rod, with a loop at one end.
These foundry tools are used to rap and draw patterns from the sand. Fig. 11.46 illustrates two kinds of draw spikes.
FOUNDRY TOOLS | VENT WIRE | STRIKE OFF BAR | DRAW SPIKE | LIFTER ...
Types of Casting Tools Types of casting tools are hand riddle, shovel, rammer, sprue pin, strike bar, mallet, draw spike, vent rod, lifter, travel, slick slick, smoother, swabs, etc. Cores are used for forming internal cavities in a casting, for forming parts of molds when the pattern is difficult to draw, or for details that are difficult to make in molding sand. DRAW SPIKE Draw spike: Draw spike is shown.
It is a tapered steel rod having a loop or ring at its one end and a sharp point at the other. It may have screw threads on the end to engage metal pattern for it withdrawal from the mold. It is used for driven into pattern which is embedded in the molding sand and raps the pattern to get separated from the pattern and finally draws out it from the.
Bansal's Wiki: Foundry Shop and tools
Draw Spike: A draw spike is a pointed steel rod, with a loop at one end; it is driven into a wooden pattern to hold it when the sand is withdrawn. The draw screw is similar in shape but threaded on the end to engage metal patterns. Strike-off Bar: A strike.
To loosen the pattern from the rammed sand, a draw spike is driven into it and stroked lightly in all directions. The pattern can then be easily withdrawn by lifting the draw spike. In this manner both halves of pattern from cope and drag are removed.
Casting lab manual | DOCX
The document lists and describes various tools used in foundry operations such as mold making. It discusses 18 different tools including hand tools like rammers, shovels, and riddles used to prepare and condition sand. Pattern withdrawal tools like draw spikes, vent rods and gates cutters are described.
Finishing tools like trowels, slicks and smothers are used to refine mold surfaces. 1.13 Draw spike (screw) Draw spike are used to lift the pattern from the sand mould. Two types of draw spike are shown in the figure.
Draw pin is inserted into a wooden pattern while thread end of draw spike screws into a wooden pattern draw plate fastened to the large wooden plate or tapped hole of metal pattern. 1.14 Rapping plate. Lab report on sand mold casting process, tools, applications, limitations, and defects.
Covers experimental procedure and equipment.
